Descriere
-
Engine
Bosch, Performance CX Smart System, 250 W, 85 Nm
-
Display
Bosch, Kiox 300 + LED Remote
-
Battery
Bosch, PowerTube, 750 Wh
-
Frame family
Haibike, AllMtn Bosch CF Smart System, Carbon/aluminium
-
Fork
RockShox, 35 Gold RL, Air, 160 mm travel, Aluminium steerer tube 1 1/8″ – 1 1/2″ tapered, 15 x 110mm thru-axle Boost
-
Damper
RockShox, Deluxe Select Plus, Air, Trunnion Mount
-
Crank arm
Haibike Components, The Crank ++, Aluminium
-
Brake (front)
Shimano, MT420, 4-piston disc brake
-
Brake (rear)
Shimano, MT420, 4-piston disc brake
-
Tube
Presta valve
-
Rim
Rodi, Tryp 30, With Eyelets, Double Wall, Aluminium
-
Clamping ring
Internal hexagon, 34.9 mm
-
Rear derailleur
Sram, SX Eagle
-
Shift lever
Sram, SX Eagle, Trigger switch
-
Bottom bracket
integrated in the motor
-
Sprocket
Sram, Eagle PG1210, 11 – 50 teeth
-
Chain
Sram, SX Eagle
-
Chainring
Sram, Aluminium, 36 teeth
-
Chain guide
Nylon directmount
-
Brake lever
Shimano, MT401, Aluminium
-
Brake disc (front)
Shimano, RT30-L, 203 mm
-
Brake disc (rear)
Shimano, RT EM300L, 203 mm
-
Tyre
Maxxis, Minion DHF II, 65-622, 29 x 2.5 inch
-
Front wheel hub
Shimano, MT400-B, Centerlock
-
Rear wheel hub
Shimano, MT400-B, Centerlock
-
Spokes
Sapim, Leader
-
Handlebar
Haibike Components, TheBar ++, 780 mm
-
Grips
Haibike, MTB grips
-
Stem
Alu, A-head, 31.8 mm
-
Headset
Acros, Cable integration, Aluminium
-
Saddle
fi’zi:k, Terra Aidon X5-160
-
Seat post
Dropper-Post Remote 31.6, Aluminium, Telescope, 31.6 mm
-
Pedals
Freeridepedal, Aluminium, with Reflector
-
Permitted total weight
120.0 kg
-
Tyre (rear)
Maxxis, Minion DHR II, 71-584, 27.5 x 2.8 inch
-
Rim (rear)
Rodi, Tryp 35, Aluminium, With Eyelets, Double Wall,
