Specifications
-
-
Engine
Yamaha, PW-ST System, 250 W, 70 Nm, 25 km/h
-
Display
Yamaha, Side Switch, 1.7″ LCD, 7 functions
-
Battery
InTube, 630 Wh
-
Frame family
Haibike, FullSeven Yamaha i630, Aluminium 6061
-
Fork
RockShox, 35 Silver, Steel spring, 140 mm travel, Aluminium steerer tube 1 1/8″ – 1 1/2″ tapered, 15 x 110mm thru-axle Boost
-
Damper
RockShox, Deluxe Select, Air, Trunnion Mount
-
Crank arm
Haibike Components, The Crank +, Aluminium
-
Brake (front)
Tektro, Orion M745, 4-piston disc brake
-
Brake (rear)
Tektro, Orion M745, 4-piston disc brake
-
Tube
Presta valve
-
Rim
Rodi, Tryp 30, With Eyelets, Double Wall, Aluminium
-
Clamping ring
Internal hexagon, 34.9 mm
-
Rear derailleur
Shimano, Deore M6100
-
Shift lever
Shimano, Deore M6100, Trigger switch
-
Bottom bracket
integrated in the motor
-
Sprocket
Shimano, M6100, 10 – 51 teeth
-
Chain
Shimano, CN-M6100
-
Chainring
Steel, 38 teeth
-
Chain guide
Nylon directmount
-
Brake lever
Tektro, Orion M745, Aluminium
-
Brake disc (front)
Tektro, TR203, 203 mm
-
Brake disc (rear)
Tektro, TR180, 180 mm
-
Tyre
Schwalbe, Nobby Nic Performance, 65-584, 27.5 x 2.6 inch
-
Front wheel hub
Haibike Components, TheHub ++, 6-bolt standard
-
Rear wheel hub
Haibike Components, TheHub ++, 6-bolt standard
-
Spokes
Sapim, Leader
-
Handlebar
Haibike Components, TheBar ++, 780 mm
-
Grips
Haibike, MTB grips
-
Stem
Haibike Components, TheStem ++, A-head, 31.8 mm, 7.0 degrees
-
Headset
Feimin, A-Head Tapered, Ball bearing
-
Saddle
Selle Bassano, Reko R2 E-Sport
-
Seat post
Dropper-Post Remote 31.6, Aluminium, Telescope, 31.6 mm
-
Pedals
Freeridepedal, Aluminium, with Reflector
-
Permitted total weight
120.0 kg
-
