Descriere
-
Engine
Yamaha, PW-X3, 250 W, 85 Nm
-
Display
Yamaha, Side Switch, 1.7″ LCD, 7 functions
-
Battery
InTube, 720 Wh
-
Frame family
Haibike, AllTrail 29 PW-X3, Aluminium
-
Fork
RockShox, 35 Gold RL, Air, 140 mm travel, Aluminium steerer tube 1 1/8″ – 1 1/2″ tapered, 15 x 110mm thru-axle Boost
-
Damper
RockShox, Deluxe Select Plus, Air, Trunnion Mount
-
Crank arm
Haibike Components, The Crank ++, Aluminium
-
Brake (front)
Shimano, MT420, 4-piston disc brake
-
Brake (rear)
Shimano, MT420, 4-piston disc brake
-
Tube
Presta valve
-
Rim
WTB, ST i30 TCS, Double Wall
-
Clamping ring
Internal hexagon, 38.1 mm
-
Rear derailleur
Sram, NX Eagle
-
Shift lever
Sram, NX Eagle, Trigger switch
-
Bottom bracket
integrated in the motor
-
Sprocket
Sram, Eagle PG1210, 11 – 50 teeth
-
Chain
Sram, SX Eagle
-
Chainring
Sram, 38 teeth
-
Chain guide
Nylon directmount
-
Brake lever
Shimano, MT401, Aluminium
-
Brake disc (front)
Shimano, RT30-L, 203 mm
-
Brake disc (rear)
Shimano, RT EM300L, 203 mm
-
Tyre
Schwalbe, Magic Mary Evo TLE, 65-622, 29 x 2.6 inch
-
Front wheel hub
Shimano, MT400-B, Centerlock
-
Rear wheel hub
Shimano, MT400-B, Centerlock
-
Spokes
Sapim, Race
-
Handlebar
Haibike Components, TheBar +++, 780 mm
-
Grips
Haibike, MTB grips
-
Stem
Haibike Components, TheStem ++, A-head, 31.8 mm, 7.0 degrees
-
Headset
Acros, BlockLock, Aluminium
-
Saddle
Selle Royal, Vivo
-
Seat post
Haibike Components, Dropper-Post Remote 34.9, Aluminium, Telescope, 34.9 mm
-
Pedals
Freeridepedal, Aluminium, with Reflector
-
Permitted total weight
150.0 kg
-
Tyre (rear)
Schwalbe, Hans Dampf Evo TLE, 65-622, 29 x 2.6 inch
