Descriere
Specifications
-
-
Engine
Yamaha, PW-ST System, 250W, 70 Nm, 25 km/h
-
Display
Yamaha, Side Switch, 1.7″ LCD, 7 functions
-
Battery
InTube, 500 Wh
-
Frame family
Haibike, FullSeven Yamaha i500, Aluminium 6061
-
Fork
SR Suntour, XCM34 DS Boost, Steel spring, Travel= 120 mm, Aluminium steerer tube 1 1/8″ – 1 1/2″ tapered, 15 x 110mm thru-axle Boost
-
Damper
SR Suntour, Edge LO-R8, Air
-
Crank arm
Haibike Components, The Crank +, Aluminium
-
Brake (front)
Shimano, MT400, 180 mm, 2-piston disc brake
-
Brake (rear)
Shimano, MT400, 180 mm, 2-piston disc brake
-
Tube
Presta valve
-
Rim
Schürmann, Yak25, with eyelets, hollow rim, Aluminium
-
Clamping ring
Internal hexagon, 34.9 mm
-
Rear derailleur
Shimano, Deore M5120
-
Shift lever
Shimano, Deore M6000, Rapidfire, 10 Speed
-
Bottom bracket
Integrated in the motor
-
Sprocket
Shimano, M4100, 11 – 46 teeth
-
Chain
KMC, e10S
-
Chainring
Steel, 38 teeth
-
Chain guide
Nylon directmount
-
Brake lever
Shimano, MT401, Aluminium
-
Brake disc (front)
Shimano, RT30-M
-
Brake disc (rear)
Shimano, RT30-M
-
Tyre
WTB, Ranger Comp, 55-584, 27.5″ x 2.30″
-
Front wheel hub
Shimano, MT400-B, Centerlock
-
Rear wheel hub
Shimano, MT400-B, Centerlock
-
Spokes
Sapim, Leader, Black
-
Handlebar
Haibike Components, TheBar +++ Gravity , 780 mm
-
Grips
Haibike, MTB grips
-
Stem
Haibike Components, TheStem ++, A-head, Bar bore: 31.8 mm, 7.0 °
-
Headset
Feimin, A-Head Alloy Tapered, Aluminium, Cartridge
-
Saddle
Haibike Components, TheSaddle
-
Seat post
Haibike Components, TheSeatpost ++, Aluminium, 31.6 mm
-
Pedals
Freeridepedal , Aluminium, with Reflector,
-
Permitted total weight
120.0 kg
-
