Frame |
aluminium 6061, Steckachse X-12 (1.00) x 148mm, disc brake Post Mount |
Drive unit |
Bosch Performance Line, 250W, 65Nm, 25km/h |
Display |
Bosch Purion |
Battery |
Bosch PowerTube, 400 Wh |
Charger |
Bosch compact charger 2A |
Fork |
SR Suntour XCM32 Boost DS, steel spring/oil, Travel: 120mm, Aluschaft 1 1/8 – 1 1/2” tapered, thru-axle Boost |
Shifting system |
Shimano Alivio M3100, 9 speed |
Gear lever |
Shimano Alivio M3100, trigger switch |
Rear sprocket |
SunRace CSM90, 11-36 teeth |
Chain |
KMC e9S |
Chain ring |
38, steel |
Brake lever |
Tektro M275, aluminium |
Front brake |
Tektro M275, 180mm, 2-piston disc brake |
Rear brake |
Tektro M275, 180mm, 2-piston disc brake |
Tyres |
Impac Smart Pac, 57-622 |
Rims |
Schürmann Yak25, with eylets, hollow rim, aluminium |
Front wheel hub |
Haibike Alu Nabe Steckachse 15×110 |
Rear wheel hub |
Haibike Alu Nabe Steckachse 12×148 |
Spokes |
Sapim Leader, black |
Handlebar |
XLC Topflat 720mm |
Grips |
Haibike MTB grips |
Stem |
XLC Alu, A-head |
Head set |
A-Head Tapered, ball bearing |
Saddle |
XLC MTB |
Seat post |
XLC, patent, 31.6mm, aluminium |
Pedals |
Freeridepedal mit Reflektor, aluminium |
Total perm. weight |
120kg |
Wheel size |
29″ |
|
