Descriere
Specifications
-
-
Engine
Yamaha, PW-TE System, 250 W, 60 Nm, 25 km/h
-
Display
Yamaha, Side Switch, 1.7″ LCD, 7 functions
-
Battery
InTube, 500 Wh
-
Frame family
Haibike, Trekking Yamaha i500/i400, Aluminium 6061
-
Fork
SR Suntour, NEX E25, Steel spring, 63 mm travel, Steel steerer tube 1 1/8″ – 1 1/2″ tapered, Quick release 100mm
-
Crank arm
Haibike, Forged, Aluminium
-
Brake (front)
Alhonga, HT474, Hydraulic disc brakes
-
Brake (rear)
Alhonga, HT474, Hydraulic disc brakes
-
Tube
Dunlop valve
-
Rim
Schürmann, Yak25, With Eyelets, Double Wall, Aluminium
-
Clamping ring
quick release, Quick release, 34.9 mm
-
Rear derailleur
Shimano, Altus M2000
-
Shift lever
Shimano, Alivio M3100, Trigger switch
-
Bottom bracket
integrated in the motor
-
Sprocket
Shimano, HG200, 11 – 36 teeth
-
Chain
KMC, e9S
-
Chainring
Steel, 38 teeth
-
Brake lever
Alhonga, HT474, Aluminium
-
Brake disc (front)
Alhonga, DXR1806, 180 mm
-
Brake disc (rear)
Alhonga, DXR1806, 180 mm
-
Tyre
Continental, Contact Urban, 55-584, 27.5 x 2.2 inch
-
Front wheel hub
Haibike, TheHub ++, 6-bolt standard
-
Rear wheel hub
Haibike, TheHub ++, 6-bolt standard
-
Spokes
Sapim, Leader
-
Handlebar
XLC, Topflat, 720 mm
-
Grips
XLC, Comfort bo3
-
Stem
XLC, Alu, A-head
-
Headset
Feimin, A-Head Tapered, Ball bearingCane Creek, Viscoset, Aluminium
-
Saddle
Selle Royal, Wave
-
Seat post
XLC, Aluminium, Patent, 31.6 mm
-
Pedals
VP, E461, Aluminium, with Reflector
-
Headlight
Trelock, Bike – i Veo LS230, 20 lm
-
Rear light
AXA, Juno Ebike
-
Dynamo
via system battery
-
Carrier
Massload, Systemgepäckträger
-
Fenders
Eurofender, Tempo, ChromoplasticsSKS, Chromoplastics
-
Stand
Ursus, Mooi, Rear stand
-
Permitted total weight
130.0 kg
-
