Descriere
Specifications
-
-
Engine
Yamaha, PW-ST System, 250W, 70 Nm, 25 km/h
-
Display
Yamaha, Multi Switch, 2.8″ TFT, 16 functions
-
Battery
InTube, 630 Wh
-
Frame family
Haibike, Trekking Yamaha i630, Aluminium 6061
-
Fork
SR Suntour, Mobie A32, Steel spring, Travel= 75 mm, Aluminium steerer tube 1 1/8″, 15 x 100mm thru-axle
-
Crank arm
Haibike, forged, Aluminium
-
Brake (front)
Shimano, MT410, 180 mm, Hydraulic disc brakes
-
Brake (rear)
Shimano, MT410, 180 mm, Hydraulic disc brakes
-
Tube
Presta valve
-
Rim
Schürmann, Yak25, with eyelets, hollow rim, Aluminium
-
Clamping ring
Quick release, 34.9 mm
-
Rear derailleur
Shimano, Deore M5100
-
Shift lever
Shimano, Deore M5100, Trigger switch, 11 Speed
-
Bottom bracket
Integrated in the motor
-
Sprocket
Shimano, M5100, 11 – 51 teeth
-
Chain
KMC, e11S
-
Chainring
Steel, 38 teeth
-
Brake lever
Shimano, MT402, Aluminium
-
Brake disc (front)
Shimano, RT30-M
-
Brake disc (rear)
Shimano, RT30-M
-
Tyre
WTB, Groov-E, 61-584, 27.5″ x 2.4″
-
Front wheel hub
Shimano, MT400-B, Centerlock
-
Rear wheel hub
Shimano, MT410, Centerlock
-
Spokes
Sapim, Leader, Black
-
Handlebar
XLC, Topflat, 720 mm
-
Grips
XLC, Comfort bo3
-
Stem
XLC, Alu, A-head
-
Headset
Feimin, A-Head Tapered, Ball bearing
-
Saddle
Selle Royal, Wave
-
Seat post
XLC, Aluminium, Patent, 31.6 mm
-
Pedals
VP, E461, Aluminium, with Reflector
-
Headlight
Haibike, Skybeamer 150, 50 lm
-
Rear light
AXA, Juno Ebike
-
Dynamo
Via system battery
-
Carrier
Massload, System carrier
-
Fenders
Eurofender, Tempo, Chromoplastics
-
Stand
Ursus, Mooi , Rear stand
-
Permitted total weight
130.0 kg
-
